[Thai Taxi TukTuk]

Thai Taxi "TukTuk Catalogue

사용자 삽입 이미지

ICON

Taxi type

Getting on of three person

AV

Aluminum van

Single person

SABAI & SABAI-L

Soteu Taxi type

Getting on of 7-13 person

FC

freezer truck

Single person

WISE & WISE-L

Long type

Getting on of 5-7 person

VT

Track type

Single person

MIGTY

Track type(hood roof)

Single person

DT

Dump

Single person


Type W×L×H(cm) Weight(kg) Capacity Wheelbase(cm)

Fuel tank()

Size of F tire(inch)
ICON 150×310×180 550 4 260 25 500-10
SABAI 130×340×200 600 7~13 260 25 500-10
VT 135×370×180 500 1 260 25 500-10
AV 140×385×200 700 1 260 25 500-10
DT 135×370×180 700 1 260 25 500-10
FC 140×385×200 700 1 260 25 500-10
MIGTY 135×370×180 500 1
260
25 500-10

Spec (all model)
Engine Daihatsu three-cylinders OHC of EF type water-cooled four cycles
Classification Three cylinders   Four strokes
Displacement 659cc
Cooling system Water-cooled
Boa × stroke  68.0×60.5 (mm)
Maximum output  Net 38/5,600(ps/r.p.m)
Max torque 5.5/4,000 (kg-m/r.p.m)
Maximum speed 90(km/h)
Clutch Dry single board diamond Fullum spring
Transmission 4MT *(Advancement 4   junior 1) There is five velocity specification and AT specifications.
Suspension
F-double shock & Coilhaidororiccsas
& Absorbarsas of R - reef spring
Brake Drum brake (Only R ) & hand parking brake.
Meter Speed meter, fuel gauge, and water temperature meter
Option Digital clock, roll bar, Ranshet, and disk brake and others

사용자 삽입 이미지


사용자 삽입 이미지
사용자 삽입 이미지
